Imaging Source DMK 42BUC03 Monochrome Industrial Camera
Product Highlights
- USB 2.0 Monochrome
- 1/3″ Micron CMOS
- Global Shutter
- 1280×960 Resolution
- Up to 25fps
- Trigger Input + I/O
$229.00
We usually have a majority of these items in stock. Please call or contact us for availability.
Description
Specifications
Downloads
Imaging Source DMK 42BUC03
Monochrome Industrial Camera
The Imaging Source DMK 42BUC03 Monochrome Industrial Camera is a cutting-edge device with USB 2.0 connectivity, designed for high-performance imaging applications. Featuring a 1/3″ Micron CMOS sensor with Global Shutter technology, this camera delivers crisp and clear images at a resolution of 1280×960. With a frame rate of up to 25fps, it ensures smooth video capture. Additionally, the camera is equipped with Trigger Input + I/O for seamless integration into industrial automation systems.
| Dynamic Range | |
|---|---|
| Video Format |
1280×960 (1.2 MP) RGB24 @ 25 fps, 1280×960 (1.2 MP) Y800 @ 25 fps |
| IR-Cut Filter |
No |
| Sensor Type | |
| Sensor Specification |
onsemi MT9M021 |
| Shutter | |
| Format | |
| Pixel Size | |
| MP |
1.2 MP |
| Resolution | |
| FPS |
25 FPS |
| Mono/Color |
Monochrome |
| Lens Mount | |
| Interface | |
| Supply Voltage |
4.5 VDC to 5.5 VDC |
| Current Consumption |
Approx. 250 mA @ 5 VDC |
| Auto Iris Control |
No |
| Trigger | |
| I/O | |
| Dimensions (H x W x L) | |
| Mass | |
| Adjustable Shutter |
1/10000 s to 30 s |
| Gain | |
| Temperature (Operating) | |
| Temperature (Storage) | |
| Humidity (Operating) |
20 % to 80 % (non-condensing) |
| Humidity (Storage) |
20 % to 95 % (non-condensing) |
