Imaging Source DMK 37BUX290 USB 3.1 Monochrome Industrial Camera
- 1/2.8 inch Sony CMOS STARVIS sensor (IMX290LLR)
- 1,920×1,080 (2.1 MP), up to 143 fps
- Rolling shutter
- Trigger and I/O inputs
$470.00
We usually have a majority of these items in stock. Please call or contact us for availability.
Description
Specifications
Downloads
Imaging Source DMK 37BUX290
USB 3.1 Monochrome Industrial Camera
The Imaging Source DMK 37BUX290 USB 3.1 Monochrome Industrial Cameras are equipped with highly-sensitive, low-noise Sony Pregius global-shutter sensors which offer exceptional distortion-free image quality and color fidelity.
The 9 and 12 MP cameras support the USB3 Vision standard which ensures stability and compatibility for easy integration and flexible configuration. Available in color and monochrome, the cameras feature a compact and robust industrial design and support applications such as intelligent traffic systems (ITS), inspection tasks and automation as well as microscopy.
Additionally, their sensor sizes (2/3″ and 1/1.8″) mean they are easily combined with a variety of low-priced standard industrial lenses available.
| Dynamic Range | |
|---|---|
| Video Format | |
| IR-Cut Filter |
No |
| Sensor Type | |
| Sensor Specification |
Sony IMX290 |
| Shutter | |
| Format | |
| Pixel Size | |
| MP |
2.1 MP |
| Resolution | |
| FPS |
143 FPS |
| Mono/Color |
Monochrome |
| Lens Mount | |
| Interface | |
| Supply Voltage |
4.75 VDC to 5.25 VDC |
| Current Consumption |
Approx. 260 mA @ 5 VDC |
| Auto Iris Control |
No |
| Trigger | |
| I/O | |
| Dimensions (H x W x L) | |
| Mass | |
| Adjustable Shutter |
20 µs to 30 s |
| Gain | |
| Temperature (Operating) | |
| Temperature (Storage) | |
| Humidity (Operating) |
20 % to 80 % (non-condensing) |
| Humidity (Storage) |
20 % to 95 % (non-condensing) |
