HIR15-500M Series
- 1/1.9″ sensor
- 33x Zoom
- f = 15.2 – 500mm
- F3.0
- True NIR
- Visible Cut Filter
- Thermal Compensation System
- OPTIONS: Serial Control Manual Override Iris Potentiometer
- C-Mount
We usually have a majority of these items in stock. Please call or contact us for availability.
Description
Specifications
The HIR15-500 lenses are powerful infrared (IR) corrected motorized zoom lenses. The IR corrected SD Glass (special low dispersion glass) has lower chromatic aberration than ED glass (extra-low dispersion glass) which allows the lens to always stay in focus, from visible light to infrared light. With a 15-500mm focal length the HIR15-500 can benefit almost any application. Designed to fit a C-Mount camera with a 1/2″ CCD or smaller, this can also be used on a CS-Mount camera with an additional C/CS adapter.
| Range Testing
|
Special Low Dispersion Glass
|
|
| Visible Lens vs. IR Corrected Lens: Notice with this IR Corrected lens utilizing the Haze Filter: You can see through haze revealing details in the mountains. |
||
 Visible Mode vs IR Corrected Mode with Haze Filter |
 Visible Mode vs IR Corrected Mode with Haze Filter |
|
